Network cable UTP Cat5e copper cable HDMI cable

Material Instruction: 1.24/25 AWG Soft Plain Copper or CCA. 2. Eco-friendly, pollution-free and new materials selected. Promise new material only. 3. Insulation: Solid HDPE; 4. Eco-friendly PVC/LSZH Jacket, high-temperature resistance, long working life.  TypeUTP CAT5eConductor24/25 AWG CU/CCA/CCAGI

Featured Products


LAN Cable UTP Cat5e Copper Wire HDMI Network Cable

Material Instruction:
1.24/25 AWG Soft Plain Copper or CCA.
2. Eco-friendly, pollution-free and new materials selected. Promise new material only.
3. Insulation: Solid HDPE;
4. Eco-friendly PVC/LSZH Jacket, high-temperature resistance, long working life.


TypeUTP CAT5e
Conductor24/25 AWG CU/CCA/CCAG
InsulationFoam PE
Total number of insulated conductor8, twisted in 4 pairs
Color codeWhite-blue/blue, white-orange/orange,
White-green/green, white-brown/brown
Operating temperature-20 ° C - +60 ° C
Drain wire/
SheathPVC/PE/LSZH
LAN Cable UTP Cat5e Copper Wire HDMI Network Cable
Impedance 1.0-100.0MHz (ohms)100±15
D. C, Resistance @20ºC(ohms/km)≤9.5
D. C. Resistance Unbalance(%)Max 2.5
Insulation Resistance>5000MΩ*KM
Rated Temperature70ºC

Frequency
(MHz)
Return loss
(dB)
Attenuation
(dB/100m)
NEXT
(dB)
FEXT
(dB)
120.002.106463.8
423.014.305551.7
1025.006.604943.8
1625.008.204639.7
2025.009.204437.7
31.2523.6411.804233.8
6221.5417.103727.6
10020.1122.003423.6
LAN Cable UTP Cat5e Copper Wire HDMI Network Cable

LAN Cable UTP Cat5e Copper Wire HDMI Network Cable

LAN Cable UTP Cat5e Copper Wire HDMI Network Cable

 Delivery TimePayment TermsShipping Method
Samle Order1-3days100% in AdvanceBy Air
LCL Order3-25days30% Deposit and the Balance Paid
Before Shipment Or Against B/L Copy
By Air Or By Sea
FCL Order25-45daysBy Air Or By Sea


LAN Cable UTP Cat5e Copper Wire HDMI Network Cable

Linan Chuangxiang Cable Co., Ltd
is a professional cable manufacturer in China,we have more than 11years in this line.

Our productions comply with ISO9001.Professional team,powerful factory and strict quality control give best service to our clients
and the quality guarantee in every order.

Our products have been widely installed in Telecom companies and many distributors around the world,and we sincerely look for-
ward to woking with all clients from all over the world.

LAN Cable UTP Cat5e Copper Wire HDMI Network Cable

Our Main Products:
1,Optical Fiber Cable and Patch Cord
2.Lan and Network Cable and Patch Cord

3.Alarm Cable and Speaker Cable
4.Drop Wire and Telephone Cable
5.Communication Cable
6.Coaxial Cable
7.Electrical Wire and Power Cable
8.Telecom Accessory.


LAN Cable UTP Cat5e Copper Wire HDMI Network Cable

1. Are you the real manufacturer?
Yes. We are the real manufacturer, which is specialized in coaxial cable, lan cable and optical cable, etc.

2. Can you accept small order?
Yes, We support new project of our customers, and we know business is always from small order.

3. What is your delivery time?
Usually within 30days after we received deposit.

4. What is your payment way?
T/T, L/C, it can be negotiated.

5. Can you supply customized products and logo?
Yes. We supply OEM&ODM service.

6, Could you supply door to door service?
Yes, by air or by express (DHL, FEDEX, TNT, EMS, SF7-10 days to your city)

7, What about the lead time for mass production?
Honestly, it depends on the order quantity and the season you place the order. Generally speaking, we suggest you start inquiry
Three to four months before the date you would like to get the products at your Country.


If you were interested in our competitive products, pls do not hesitate to contact me!
